ST XTA Coilovers allow you to maximize the driving dynamics of your car if you are a sporty ambitious driver. With the linear race spring system, adjustable dampers, and aluminum uniball camber adjustable top mounts, you can individually adjust the cars behavior with just a few tweaks. Whether its style or performance, with ST XTA Coilovers you are in control.
Features
Front Lowering: 0.8" to 1.6"
Rear Lowering: 0.6" to 1.6"
18 Distinct clicks of Rebound Damping Adjustability
Solid Aluminum uniball top mounts (camber adjustable depending on application)
Linear Race springs
Reduced system friction for effective damping adjustment
Individual lowering within the tested height adjustment range
Front and rear axle thread adjustment (when possible)
Galvanized coilover struts with additional coating for optimized corrosion protection
Complete solution with adjustable spring perch, multi-coated spring system and dynamic elastomer bump stops with dust protection
Powerful twin-tube dampers with high-quality components for maximum longevity
Backed by ST suspension's 5 Year Unlimited Mileage Warranty
Individually Height Adjustable ST XTA Coilover kits deliver precise adjustment to your ride height so you control the look of your car. We manufacture the adjustable spring perch made of durable and friction-optimized polyamide composite material with a stainless steel insert. Thanks to the composite material corrosion is prevented between the strut and perch ensuring long lasting height adjustability while the stainless steel insert provides strength and confidence!
Control The Details More control of the driving dynamics thanks to adjustable KW rebound technology. ST XTA Coilovers come preset to our factory recommended damper settings, the same configuration we test them at on our KW shock dynos before they go into your box. The 18 distinct clicks of adjustable rebound damping allow you to refine the driving dynamics with a simple turn of the adjustment knob. Each kit includes a detailed damper setup manual making it easy to reset to our recommended setting at any time. Whether your preference is comfort, performance, or something in between; ST XTA puts the finer details of the driving dynamics in your hands.
Turning the adjustment knob to the right, you increase the rebound force and achieve tighter handling. High rebound forces (closed rebound) improve the handling response, this is especially noticeable on the front axle; the response is a direct and unadulterated sporty experience. This closed rebound stage is ideal if you enjoy spirited drives, long curved banks, canyon carving, and more.
Characteristics at a closed rebound stage:
More direct steering
Improved handling
Pitch and roll movements of body are greatly reduced
Turning the adjustment knob to the left your ST Coilover suspension will provide a much smoother ride and improved ride comfort compared to standard shocks and lowering springs. This is ideal when driving on uneven and rough roads by helping to absorb road frequencies. The opened rebound stage takes ride comfort to the next level.
Characteristics at opened rebound stage:
Increased rolling comfort
More driving comfort
Precise handling due to adjustable unibal top mounts The top mounts included with our ST XTA Coilover kits allow you to adjust the camber at the front axle to dial in aggressive wheel and tire fitment. They also allow you to maximize the tire's contact patch for driving in fast corners and any other driving scenario that demands maximum grip.
Galvanized steel struts
Low friction materials with layers of protection
Galvanized zinc coated steel struts optimize corrosion protection for long lasting use. We add a dust protection system to prevent unwanted dirt and particulate from coming in contact with the hardened chrome piston rod or getting into the valve packs. We reinforce the system with a multi-layered pressure resistant sealing package, mono block guide system and a low friction piston band which works inside the pressure resistant internal damper housing.
Unique Features The high quality ST XTA Coilovers have numerous unique features that provide unparalleled value and a long lasting durability.
Composite Spring Perches
two-Piece Racing Spring System
Dust Protection and Weather-Resistant
KW Quality – exclusively for ST suspensions The ST suspensions coilovers benefit from our many years of experience in the development and production of suspension components for motorsport and the street. Each damper is hand assembled specifically for your order and put through rigorous quality control testing before being placed in your box for delivery.
Note:KW Code Isolator Kit not included (available separately). Vehicles equipped with EDC will require KW EDC Code Isolator Kit or have EDC option coded off to prevent errors.
Vehicles Supported BMW F87 M2 Competition BMW F8X M3/M4, including Competition
